HTML Tutorial: Angular 7/8 Template Syntax - Interpolation, ngFor & ngIf Directives

In this tutorial, we’ll teach you HTML which is used as the template language for Angular. We’ll build a simple HTML “app” using JAMStack approach and we'll learn about the Angular advanced concepts (Such as data binding, interpolation, loops with the ngFor directive , and conditional rendering with the ngIf directive). HTML is a prerequisite in any web development and one of the three pillars of the web along with JavaScript (or compiled TypeScript) and CSS.

Note: HTML is the language of Angular templates

What is HTML?

HTML stands for HyperText Markup Language is an artificial markup language that can be used by programmers to create the structure of web documents. It’s one of the three pillars of the web along with JavaScript and CSS. It can be interpreted by a web browser which transforms an HTML source code comprised of HTML tags to an actual web page with text, tables, forms and links etc.

How Does Angular Use HTML?

A web browser can only understand plain HTML, JavaScript and CSS. While Angular uses HTML for creating views, it adds some template structures such as loops and conditional directives along with other syntax symbols for variable interpolation and data binding which are not part of HTML thus they are compiled ahead of time and transformed to plain HTML.

An Angular application is executed when a typical index.html file is served to the browser:

<!doctype html>
<html lang="en">
<head>
  <meta charset="utf-8">
  <title>Angular Demo</title>
  <base href="/">
  <meta name="viewport" content="width=device-width, initial-scale=1">
  <link rel="icon" type="image/x-icon" href="favicon.ico">
  <link href="https://fonts.googleapis.com/css?family=Roboto:300,400,500&display=swap" rel="stylesheet">
  <link href="https://fonts.googleapis.com/icon?family=Material+Icons" rel="stylesheet">
</head>
<body>
  <app-root></app-root>
</body>
</html>

The JavaScript bundles for Angular are built and injected into the index.html file after building the application.

Except for the typical HTML tags, we also have a custom <app-root> tag which is used to include the Angular root component which is by convention called App. This will result in including all the children components and eventually the full Angular application.

Angular also uses HTML for the individual components' templates which are used to create the views of the application.

For example, the root component in an Angular application generated with the official Angular CLI has an associated template called app.component.html. This is not a convention as we should explicetly tell the component where to find the template. This is done using a templateUrl meta-property as follows:

import { Component } from '@angular/core';

@Component({
  selector: 'app-root',
  templateUrl: './app.component.html',
  styleUrls: ['./app.component.css']
})
export class AppComponent {
  title = 'Angular Demo';
}

We can also use an inline HTML template using a template property.

Note: The <html>, <body>, and <base> tags have no useful role in Angular templates.

Angular Template Syntax

In Angular templates, you can use plain HTML but also special syntax and directives that allow you to take benefits of the full power of Angular features such as interpolation, binding, ngClass, ngStyle, ngFor and ngIf, etc.

Interpolation

Interpolation enables you to use variables and expressions in your HTML template, either between HTML element tags or within attribute assignments.

You can embed a variable or expression in your HTML templates using the double curly braces, ``.

For example, in the previous App component, we have a title variable with an initial value of Angular Demo. We can use interpolation to display this value in the related app.component.html template:

<h1>{{title}}</h1>

Angular will dynamically replace the title variable with its value in the template.

Note: You can change default interpolation delimiter used by Angular by using the interpolation property in the component metadata.

Angular Built-In Directives: ngFor and ngIf

Angular provides many builtin directives such as ngFor for iterating over arrays of data and ngIf for conditionally rendering HTML elements.

The ngFor directive allows you to iterate through arrays in your HTML templates while ngIf allows you to express conditions in your template. These are powerful programming-like constructs that extend HTML thanks to Angular.

We'll see below how to use ngFor and ngIf with a practical example.

Extending HTML with Angular Components and Directives

Angular allows you to extend the HTML vocabulary of your templates with components and directives that can be considered as new elements and attributes.

What is an HTML Document?

An HTML document is simply a plain text document with the .html extension instead of .txt

Most tags have opening and closing parts. Each tag begins with < symbol and ends with > symbol. For example:

  • The topmost tag that defines and HTML document is <html></html>. All the content should be contained between the opening and closing tags.
  • The body tag that defines the body of the web page is <body></body>.
  • The tag to add a title of the page is <title> … </title>. etc.

Tags can have attributes that provide extra information to the browser for how to display the element.

Web servers serve only plain HTML to web browsers without any server-side programming constructs.

HTML is an essential requirement if you want to create websites. Most developers start their journey in web development by learning HTML, this is the case for both frontend developers that use JavaScript to create client-side apps and backend developers that use server-side languages like PHP or Python to create web apps.

Notes: You can also use JavaScript frameworks like Angular or libraries like React or Vue to create apps with JS and HTML. All these tools, make use of components that use HTML as the template language for creating views.

You can extend HTML by creating new tags using custom elements and web components which are standard browser technologies that don’t require a third-party tool, framework or library to be interpreted by the browser.

Prerequisites

You don’t need a fully-fledged development environment with a lot of tools installed to start learning HTML. You only need a text editor (that optionally has syntax highlighting for HTML) and a web browser like Chrome or Firefox or even IE.

You also need some basic knowledge to work with your operating system, Windows, Linux or macOS, particularly how to create and open files.

You can also use online development environments such as CodePen, JSBin or JSFiddle for trying HTML without creating files in your computer. Actually, these online environments are most useful if you are unable to create files in your system or you are using devices like phones and tablets while you are learning HTML, JavaScript or CSS.

In this tutorial, I’ll assume you are working with a Unix-based terminal (present in macOS or Linux) and can be installed on Windows. Don’t worry though, the command we’ll use is for navigating to a working folder and creating a file, you can do this in your preferred way.

HTML is not a programming language but instead a markup language that you can use to apply tags on some text to give it a semantic or meaning, create a structure for a page like header, footer, columns, sections and navigation menus. It can be also used to add images and videos to your pages from local or external sources.

Note: A programming language has advanced constructs and features like loops for iterating over arrays of data and conditional statements for making decisions etc. HTML doesn't have these constructs so It can’t be considered as a programming language since It just displays and formats visual elements on a web page.

Many template languages are built on top of HTML to provide these constructs. For instance, Angular provides a template syntax that includes data binding like interpolation for easily updating the page with data from the parent component, and directives such as *ngFor and *ngIf for iterating over data and displaying HTML elements conditionally.

Creating the very basic HTML document

Go ahead and open a terminal and run the following commands:

$ cd ~
$ mkdir my-first-webpage
$ cd my-first-webpage
$ touch index.html

We simply navigate to the home folder. Next, we create a folder called my-first-webpage. Next, we navigate inside it and create an index.html file.

Now, use a text editor (like Vim or whatever you prefer) and open the index.html file. Next, simply add the following code:

<!DOCTYPE html>
<html>
  <head>
    <title>My first HTML page</title>
  </head>
  <body>
    <p>This is my first web page</p>
  </body>
</html>

We first add a doctype which must be present. Nowadays in modern browsers that understand HTML5 it’s mostly useless, but required. In the old days, it was used to link to some type definition documents that contain syntax rules of the language.

According to Wikipedia, this is the definition of a doctype:

A document type declaration, or DOCTYPE, is an instruction that associates a particular SGML (for example, a webpage) with a document type definition(DTD) (for example, the formal definition of a particular version of HTML 2.0 - 4.0) or XML document. In the serialized form of the document, it manifests as a short string of markup that conforms to a particular syntax.

Next, we add an opening <html> tag with its closing </html> tag which mark the start and end of the HTML code. Between these two tags, you can add the necessary code for creating your web page.

Next, we add the head section of the document using the <head> and </head> tags: The [<head>](https://developer.mozilla.org/en-US/docs/Web/HTML/Element/head) element is sort of a container for all the tags that represent some information about your document such as the title which is added using a <title> element. Inline CSS styles or links to external CSS files or meta tags.

Next, we add the <body></body> section which contains the content of your web page.

Inside the body, we add This is my first web page paragraph wrapped by the <p> and </p> tags.

Now, go ahead and open the index.html file with your web browser (Make sure to save its content in the text editor). You should not see the tags but a rendered blank page with This is my first web page just like in the following screenshot:

My first HTML page

Escaping Special HTML Characters

HTML has a set of special characters such as < and > which are used to surround the tag names also characters like " and ' used for the values of tag attributes and &. So, how can you display these characters in your HTML page? i.e tell the browser not to interpret them but simply display them like regular content. You can do this by escaping these characters using their codes:

Each code begins with & and ends with ;.

HTML Comments

When you are writing HTML code, you may need to comment your code but you don’t want these comments to appear in the web page since they are only intended for your or other developers that read the source code of your web page.

To write a comment, HTML provides <-- and --> tags. You should surround you comment with them. For example!

<!-- This is a comment -->

Note: In web browsers, you can read the source code of any web page that is currently displayed without any restrictions using View page source from a contextual menu or pressing CTRL + U in your keyboard. These instructions are valid for Chrome but you should find similar instructions for other browsers.

HTML Links and Navigation

HTML provides hypertext links using the <a> tag which works by surrounding a text that becomes the link. The target page is specified using the href attribute. For example:

<a href="https://www.techiediaries.com">Go to Techiediaries</a>

The href value can reference a local HTML document using its relative path or an external document using its URL (Uniform Resource Locator).

Note: You also need to know about HTML Headers, HTML Paragraphs, HTML Sections, HTML Tables, and HTML Forms.

Let’s create a simple HTML website which has pages like home, about and contact page.

In the contact page, we’ll add an HTML form and thanks to cloud services users can submit their information without needing to add a backend for our app, we’ll use a cloud service FormSpree which allows us to get what usesr submit using our form via emails.

Can you build something useful with HTML alone?

Yes, you can! Not fully-fledged apps but you can create a static HTML website which you can use to share information with your visitors. You’ll be able to create multiple pages and add navigation between them and you can add content, paragraphs, divisions, sections, headlines and horizontal lines which are enough to present a document or article with a basic appearance.

But if you want to take it further, you can use a front-end framework like Angular to build powerful apps that can be hosted in a web server and even server rendered in the server before sent the browser which are required for SEO and performance purposes.

Note: You can actually create fully-working static sites following the JAMStack modern approach.

What is JAMstack?

According to the official website:

JAMstack: noun \’jam-stak’\ Modern web development architecture based on client-side JavaScript, reusable APIs, and prebuilt Markup.

JAMstack stands for JavaScript, APIs, and Markup. The term is first used by Mathias Biilmann to describe a modern web development architecture based on JavaScript, APIs, and prebuilt Markup.

When you build a JAMstack app, you only serve HTML using a CDN instead of doing any server-side preprocessing. This results in faster loading times, and less security problems.

You maybe thinking how can we build real-world useful web apps using JAMstack and without a server since even a simple form submission needs a backend server?

But in fact, the web has known a big essor in SaaS products that allow you to do any kind of server functionality via a simple API without the need to build it yourself. For example:

  • SaaS products like Snipcart, Foxy.io, Moltin and Shopify’s Buy Button can be used for ontegrating e-commerce services in your JAMstack app.
  • SaaS products like FormKeep, Typeform, Formspree, and even Netlify can be used for processing form.
  • SaaS products like Algolia, Google Custom Search, Fuse.js, Lunr.js and List.js can be used for integrating search functionality.
  • Apps like Disqus and Staticman can be used for user-generated content like comments & reviews, etc.

Building a Web App with Angular 7/8 and HTML

Now, let's build a JAMstack application with Angular, HTML and a third-party API. The app is simply a news app that can be served from a CDN like Netlify. It's made of only HTML, CSS and JavaScript.

Note: Angular makes use of TypeScript but this will be compiled to plain JavaScript in the development machine before hosted on a CDN.

Installing Angular CLI 8

The Angular CLI is the offical tool for initializing and working with Angular projects. It's based on Node.JS and can be installed from NPM. Open a new terminal and run the following command:

$ npm install -g @angular/cli

Creating an Angular 8 Project

Next, we can initialize an Angular 8 project using the following command:

$ ng new angular-html-demo

You'll be asked by the CLI if you Would you like to add Angular routing? Type y for Yes and Which stylesheet format would you like to use? Choose the first option which is CSS.

Next, navigate to your project’s root folder and run the development server using the following commands:

$ cd angular-html-demo
$ ng serve

You'll be able to visit your Angular app by pointing your web browser to the http://localhost:4200/ address:

This is how your app looks but this is just placeholder content that you need to replace with your actual content.

Let's open the src/app/app.component.html template that is associated with the root component and remove all the placeholder markup and leave only the router outlet directive for now:

 <router-outlet></router-outlet>

If you are not familiar with the standard HTML element tags, you would think that this is part of HTML but it's actually an Angular directive from the router library that tells the client-side router where to insert the component matching the currently-visited path.

Creating and Adding Components to the Router Configuration

Angular components and directives allow you to reuse and extend HTML templates. In our example application, we can have the following components:

  • Header, navbar and footer shell components,
  • Home and about page components.

The home and about page components are mapped to specific routes, so they only appear when we we navigate the appropriate route.

While, the header, navbar and footer components belong to the shell of the application which resides in the src/app/app.component.html template.

Open a new terminal and run the following commands to generate the components and their HTML templates:

$ ng generate component home
$ ng generate component about
$ ng generate component header
$ ng generate component navbar
$ ng generate component footer

We'll have many folders with the TypeScript, CSS files, and HTML templates for each component.

You can see that Angular provides a powerful structure for our application than if you are using plain JavaScript, CSS and HTML files.

Adding Angular Routing

Angular routing allows you to control which HTML templates are rendered when a specific route is visited in the browser which allows you to create fully-fledged apps with JavaScript and HTML completely in the client-side without resorting to server routing.

Let's add the home and about components to the router configuration. Open the src/app/app-routing.module.ts file and update as follows:

import { NgModule } from '@angular/core';
import { Routes, RouterModule } from '@angular/router';
import { HomeComponent } from './home/home.component';
import { AboutComponent } from './about/about.component';


const routes: Routes = [
  { path: '', redirectTo: 'home', pathMatch: 'full'},
  { path: 'home', component: HomeComponent },
  { path: 'about', component: AboutComponent },
];

@NgModule({
  imports: [RouterModule.forRoot(routes)],
  exports: [RouterModule]
})
export class AppRoutingModule { }

Next, let's add the header, navbar and footer components to the app shell. Open the src/app/app.component.html file and update it as follows:

<app-header></app-header>
<app-navbar></app-navbar>
<router-outlet></router-outlet>
<app-footer></app-footer>

How do we know the tag names of each component. You can get and even change the selector used for a component from the associated TypeScript file of the component. For example, this is the header component:

import { Component, OnInit } from '@angular/core';

@Component({
  selector: 'app-header',
  templateUrl: './header.component.html',
  styleUrls: ['./header.component.css']
})
export class HeaderComponent implements OnInit {

  constructor() { }

  ngOnInit() {
  }

}

The selector property contains the app-header value which means we can include the component in HTML using <app-header /> or <app-header></app-header>.

If you save your changes, you should see the home page:

Now, let's add some HTML markup to our components. Open the src/app/home/home.components.html file and add the following HTML markup:

<h2>Home</h2>

<p>This is a JAMstack app built with Angular 8</p>

Next, open the src/app/about/about.component.html file and add the following HTML code:

<h2>About us</h2>
<p>This app is built by Techiediaries.</p>

Next, open the src/app/navbar/navbar.component.html file and add the following HTML code:

<a  [routerLink]="['/home']">HOME</a>
<a  [routerLink]="['/about']">ABOUT US</a>

We use the standard <a> tag in HTML and the routerLink directive in Angular to specify the navigation routes instead of the standard href attribute in HTML.

Next, open the src/app/header/header.component.html file and add the following markup;

<header>
    <h1>Angular 8 + HTML App</h1>
</header>

Next, open the src/app/footer/footer.component.html file and add the following markup;

<footer>
    <span>
        Copyright 2019
    </span>
</footer>

Note: You can see how we are able to use HTML fragments to create the UI of our application thanks to Angular routing and the powerful template syntax.

Now, how we do get and display data in our application?

Angular provides the HTTP client that we can use to fetch data from third-party APIs. Before we can use it, we only need to import its module and add it to the root module of our application. Open the src/app/app.module.ts file and update it as follows:

// [...]

import { HttpClientModule } from '@angular/common/http';

@NgModule({
  declarations: [
    // [...]
  ],
  imports: [
    BrowserModule,
    AppRoutingModule,
    HttpClientModule,
  ],
  providers: [],
  bootstrap: [AppComponent]
})
export class AppModule { }

Next, open the src/app/home/home.component.ts file and import then inject HttpClient as follows:

import { Component, OnInit } from '@angular/core';
import { HttpClient } from '@angular/common/http';

@Component({
  selector: 'app-home',
  templateUrl: './home.component.html',
  styleUrls: ['./home.component.css']
})
export class HomeComponent implements OnInit {

  private API_KEY = "YOUR_API_KEY_HERE";
  private API_ENDPOINT = `https://newsapi.org/v2/everything?q=comics&sortBy=publishedAt&apiKey=${this.API_KEY}`;
  data = [];




  constructor(private httpClient: HttpClient) { }

  ngOnInit() {

  }

}

Next, in the ngOnInit() method, call the get() method to fetch data from the remote API:

import { Component, OnInit } from '@angular/core';
import { HttpClient } from '@angular/common/http';

@Component({
  selector: 'app-home',
  templateUrl: './home.component.html',
  styleUrls: ['./home.component.css']
})
export class HomeComponent implements OnInit {

  private API_KEY = "YOUR_API_KEY_HERE";
  private API_ENDPOINT = `https://newsapi.org/v2/everything?q=comics&sortBy=publishedAt&apiKey=${this.API_KEY}`;
  data = [];

  constructor(private httpClient: HttpClient) { }

  ngOnInit() {
    this.httpClient.get(this.API_ENDPOINT).subscribe((data) =>{
      console.log(data['articles']);
      this.data = data['articles'];
    });
  }

}

Now, you should see your fetched data displayed in the console of your web browser but how do we display these data in the corresponding HTML template?

Angular Template Syntax: Interpolation, ngFor and ngIf

Here comes the magic of Angular template syntax and directives such as ngFor and ngIf.

Open the src/app/home/home.component.html file and update it as follows:

<div class="container">

  <div *ngIf = "data.length === 0">
    <p>
      Loading data...
    </p>

  </div>

    <div *ngFor="let article of data" class="card">
        <img src="{{ article.urlToImage }}">
                <div class="card-body">
                    <h3>{{ article.title }}</h3>
                    <p> {{ article.description }}</p>
                    <a href="{{article.url}}">Read story</a>
                </div>
            </div>

</div>

Using the ngIf directive, we conditionally render the Loading data... message while the data array is empty. When data is fetched and populatd in the data array, the message will disappear and ngFor will take care of iterating through and displaying each article of the data array.

We use interpolation to display the value associated with each article property.

Before we see the final result, let's add a bit of CSS styling to our HTML template. Open the src/app/home/home.component.css file and add the following CSS:

h1 {
    color: purple;
    font-family: 'kalam';
}

.container {
    display: grid;
    grid-template-columns: repeat(auto-fill, minmax(305px, 1fr));
    grid-gap: 15px;
}

.container > .card img {
    max-width: 100%;
}

Next, open the src/app/navbar/navbar.component.css and add the following CSS code :

:host {
    border: 0 solid #e1e1e1;
    border-bottom-width: 1px;
    height: 49px;
    padding: 0 16px;

    display: flex;
    flex-flow: row;
    align-items: center;
  }

  a {
    color: #c697d8;
    font-size: 19px;
    font-weight: 900;
    line-height: 49px;
    margin-right: 27px;
    text-decoration: none;
  }
}

Next, open the src/app/header/header.component.css file and add the following CSS code:

:host {
    color: rgb(25, 143, 221);

    border-top: 0px solid #9154f3;
    border-bottom-width: 1px;
    padding: 0 17px;
}

Now, this is our home page with the fetched data:

Check out the example in Stackblitz:

Conclusion

In this HTML tutorial, we've learned about HTML with Angular 7/8 example. We've seen the basic concepts of HTML and how Angular extends HTML with powerful template syntax and directives such as ngFor and ngIf.

We've also seen the concept of the modern JAMstack appoarch of building apps with JavaScript, HTML and CSS which can be served via a CDN and consume data via APIs.

Note: We also publish our tutorials on Medium and DEV.to. If you prefer reading in these platforms, you can follow us there to get our newest articles.

You can reach the author via Twitter:

About the author

Ahmed Bouchefra
is a web developer with 5+ years of experience and technical author with an engineering degree on software development. You can hire him with a click on the link above or contact him via his LinkedIn account. He authored technical content for the industry-leading websites such as SitePoint, Smashing, DigitalOcean, RealPython, freeCodeCamp, JScrambler, Pusher, and Auth0. He also co-authored various books about modern web development that you can find from Amazon or Leanpub


Get our Learn Angular 8 in 15 Easy Steps ebook in pdf, epub and mobi formats, plus a new Angular 8 tutorial every 3 days.


Online Courses (Affiliate)

If you prefer learning with videos. Check out one of the best Angular courses online
Angular 8 - The Complete Guide (2019+ Edition)

Angular Crash Course for Busy Developers

comments powered by Disqus
DMCA.com Protection Status
