RxJS 6 for Angular Developers Tutorial by Example

RxJS 6 for Angular Developers Tutorial by Example

In this RxJS 6 for Angular developers tutorial you'll learn about the latest version of RxJS, a library that implements Reactive programming in JavaScript. You'll learn about the core RxJS 6 concepts such as Observables, Observers, Subjects, Streams, Subscriptions and Operators.

In this tutorial, we'll setup a development environment to work with RxJS 6 library. In the next tutorial, we'll see how to use RxJS Observables.

Installing RxJS 6 Library

Before you can use RxJS 6 in your project you need to install it in your project. If you are using frameworks like the latest Angular 6 you'll have RxJS 6 already installed and integrated. If not then you can follow these steps to properly add RxJS to your project.

First, let's quickly setup a TypeScript project with Webpack.

Open your terminal and create a folder for your project:

$ mkdir rxjs6-demo

Navigate inside the created folder and create a package.json file with the following content:

  "name": "rxjs6demo",
  "version": "1.0.0",
  "main": "index.js",
  "license": "MIT",
  "dependencies": {},
  "scripts": {}

Next, install the following dependencies using npm:

npm install --save rxjs webpack webpack-cli webpack-dev-server typescript ts-loader

Add a start script which launches the webpack development server in development mode:

  "scripts": {
    "start": "webpack-dev-server --mode development"

Setting Up Webpack

Inside your project's root folder create a webpack.config.js file with the following content:

const path = require('path');

module.exports = {
  entry: './src/main.ts',
  devtool: 'inline-source-map',
  module: {
    rules: [
        test: /\.tsx?$/,
        use: 'ts-loader',
        exclude: /node_modules/
  resolve: {
    extensions: [ '.ts', '.js', '.tsx' ]
  output: {
    filename: 'bundle.js',
    path: path.resolve(__dirname, 'dist')

We define the entry point for our project as ./src/main.ts so this is where we'll add our TypeScript code. Webpack will produce a bundle.js file inside a dist folder which will include in our index.html file.

Adding a TypeScript Configuration tsconfig.json File

Inside the root folder of your project add a tsconfig.json file with the following content:

  "compilerOptions": {
    "outDir": "./dist/",
    "noImplicitAny": true,
    "module": "es6",
    "moduleResolution": "node",
    "sourceMap": true,
    "target": "es6",
    "typeRoots": [
    "lib": [

This configuration lets you use es2017 (es8) and compile to es6.

Adding an index.html File

Create an index.html file with the following content:

<!DOCTYPE html>
<html lang="en">
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <title>RxJS 6 Tutorial and Examples</title>
    <div id="main"></div>
    <script src="./bundle.js"></script>

Now create a src folder with a main.ts file and run the following command to start the webpack dev server:

$ npm start

You can use your web browser from http://localhost:8080/ to see your page.


In this tutorial, we've installed a development environment with TypeScript to start using RxJS 6 library.

In this tutorial we've seen how we can setup a development project to work with RxJS 6 and TypeScript but for Angular 6 or Angular 7, RxJS 6 is included by default so you don't need to manually install it in your project.
